Stair Construction Drawings

We provide drawings for stairs and handrails made to order. Drawings from a one page elevation to a full set ready for submission for concept, customer approval, engineering, building department, fabrication, and installation.

Residential Drawings

Stair elevation

9

Useful for including with your signed contract.

9

Elevation of one side of stair & rail.

Shop Drawing

Used for submitting to customer for approval, ordering materials, fabrication and installation.

Basic

9

Plan view including dimensions and components labeled.

9

Elevations of both sides of each flight of stairs and one sideĀ of each run of balcony rail including dimensions and components labeled

Complete

9

Details and cut sheets for components I.E. posts, balusters, hand rail hardware.

9

Finish schedule

Commercial Drawings

9

Architectural submittals

9

Structural submittals

9

Sealed engineering

Commercial Consulting

9

Value design/engineer

9

Establish budget pricing

9

Review for code compliance Building, ADA & NFPA.
